TP‑Link Deco Voice X20

Product Description

The TP‑Link Deco Voice X20 combines powerful Wi‑Fi 6 mesh networking with smart voice control and premium audio. Delivering AX1800 dual‑band speeds, seamless whole‑home coverage, and integrated Alexa functionality, the Deco Voice X20 is designed to provide both connectivity and convenience.

With TP‑Link Mesh technology, multiple units work together to form one unified network, automatically switching devices to the strongest signal as you move around. Each unit also doubles as a smart speaker with high‑quality sound, enabling voice commands and music playback throughout your home. Built‑in HomeShield security ensures safer browsing, parental controls, and IoT protection.

Key Features

• AX1800 dual‑band Wi‑Fi speeds: 1201 Mbps (5 GHz) + 574 Mbps (2.4 GHz)

• Seamless whole‑home coverage with TP‑Link Mesh technology

• Alexa built‑in for voice control and smart home integration

• Integrated smart speaker with premium sound quality

• TP‑Link HomeShield security with parental controls and IoT protection

• Full gigabit Ethernet with 2 WAN/LAN ports per unit

• Works with all Deco models to expand your mesh network

• Easy setup and management through the Deco mobile app

Wireless Specifications

• Wi‑Fi Standard: Wi‑Fi 6 (802.11ax)

• Bands: 5 GHz (1201 Mbps), 2.4 GHz (574 Mbps)

• Coverage: 3–4 bedroom homes (2‑pack)

• Antennas: 2 internal antennas with beamforming

• Capacity: Dual‑band, MU‑MIMO, OFDMA, 4 streams

• Modes: Router mode and Access Point mode

Security

• SPI firewall and access control

• WPA, WPA2, and WPA3 encryption

• HomeShield security suite with IoT protection, malicious site blocking, intrusion prevention, and DDoS defense

• Guest networks for both 2.4 GHz and 5 GHz

Hardware

• Integrated smart speaker: 5 W full‑frequency speaker with double bass passive diaphragm

• Microphone: Quadruple microphone array for voice commands

• Ports: 2 × Gigabit Ethernet per unit (WAN/LAN auto‑sensing)

• Buttons: Reset, mute, action, and volume controls

• Dimensions: 105 × 105 × 170 mm

Software and Management

• Supported Protocols: IPv4, IPv6

• HomeShield parental controls with custom profiles, content filtering, and usage reports

• WAN Types: Dynamic IP, Static IP, PPPoE, PPTP, L2TP

• QoS: Device‑based priority control

• Cloud Services: OTA firmware updates, TP‑Link ID, DDNS

• IPTV Support: IGMP Proxy, IGMP Snooping, Bridge, VLAN Tagging

• DHCP: Reservation, client list, server mode

• Management: Deco mobile app
