GWN7664ELR Grandstream AP
عن هذا المنتج
GWN7664ELR – High‑Performance Outdoor Long‑Range Wi‑Fi 6 Access Point
Ultra‑High‑Speed AX6000 Wi‑Fi 6 for Large Outdoor & Enterprise Deployments
A rugged, enterprise‑grade long‑range Wi‑Fi 6 access point designed for medium‑to‑large businesses, campuses, industrial sites, and expansive outdoor environments. The GWN7664ELR delivers exceptional throughput, extended coverage, and robust reliability for mission‑critical networks.
Description
The GWN7664ELR delivers 6 Gbps aggregate wireless throughput and features dual 2.5G interfaces (RJ‑45 + SFP) for high‑speed fiber or copper backhaul. With 4×4:4 MU‑MIMO, OFDMA, and support for 512 concurrent clients, it provides powerful performance across large outdoor areas with coverage up to 300 meters. Designed for harsh environments, it includes 8 internal antennas, PoE+ support, and enterprise‑grade security with digital signature protection.
Configuration
Wireless Performance
- WiFi Standard: IEEE 802.11b/g/n/ac/ax (Wi‑Fi 6)
- Dual‑Band Throughput:
- 2.4 GHz: 1147 Mbps (4×4:4 MU‑MIMO)
- 5 GHz: 4800 Mbps (4×4:4 MU‑MIMO)
- Aggregate Wireless Speed: 6 Gbps
- Coverage Range: Up to 300 meters
- Concurrent Clients: 512
- Technologies:
- 4×4:4 MU‑MIMO
- DL/UL OFDMA
- Beamforming
- Advanced QoS for real‑time applications
Key Features
- 6 Gbps Wi‑Fi 6 throughput
- Long‑range coverage up to 300 meters
- Dual 2.5G interfaces: RJ‑45 (PoE+) + 2.5G SFP
- 8 internal antennas for optimized outdoor performance
- Anti‑hacking secure boot & digital signature protection
- Critical data/control lockdown
- Unique per‑device certificate & random default password
- Self‑power adaptation with PoE/PoE+ auto‑detection
- Embedded controller for managing up to 50 local APs
- Full support for GDMS & GWN Manager
Hardware
- Network Interfaces:
- 1 × 2.5G RJ‑45 port (PoE input)
- 1 × 2.5G SFP port
- PoE Support:
- 802.3at (PoE+)
- Max Power Consumption: 24W
- Antennas:
- 8 internal antennas (optimized for long‑range outdoor coverage)
- Dimensions: 260 × 310 × 59 mm
- Mounting: Wall mount or pole mount (adjustable by 60°, kits included)
Security
- WPA/WPA2‑PSK
- WPA/WPA2‑Enterprise (TKIP/AES)
- WPA3
- WEP
- Secure boot
- Digital signatures
- Critical data/control lockdown
- Unique per‑device certificate
Management
- Embedded controller (up to 50 APs)
- GDMS cloud management
- GWN Manager (on‑premise)
- Web UI & mobile app
- Advanced analytics, provisioning & monitoring
Use Cases
Ideal For
- Outdoor enterprise campuses
- Industrial zones & warehouses
- Resorts, hotels & outdoor hospitality areas
- Stadiums, arenas & large event spaces
- Long‑range outdoor corridors & courtyards
- Large indoor halls & transportation hubs
Why It Works Well
- AX6000 performance handles extremely high client density
- Long‑range coverage ideal for outdoor and wide‑area deployments
- Dual 2.5G ports support high‑speed fiber or copper backhaul
- Enterprise‑grade security ensures safe, reliable connectivity
- Rugged design built for demanding environments
